PU165 is an excellent two-component aliphatic acrylic polyurethane topcoat, semi-gloss, with high solid content and excellent gloss and color retention. When used with epoxy primer or polyurethane primer, a high-strength long-term anti-corrosion system can be obtained.

Inquiry Now
Name *
Email *
Enter enquiry subject *
Message *
WhatsApp
SKU: PU166 Aliphatic Acrylic Polyurethane Topcoat Category: Tags: ,
Description

General Description

WH-PU166 is an excellent two-component polyurethane topcoat, featuring a full and glossy film with superior decorative properties, light retention, and weather resistance.

Product Characteristics

  • Excellent light retention
  • Outstanding color fastness
  • Good chemical resistance
  • Excellent recoatability
  • Low-temperature curable
  • When paired with epoxy primer, WH-PU166 forms a high-strength long-acting anti-corrosion system.

Recommended Applications

Suitable as a topcoat for structural surfaces in severe corrosion environments with high requirements for light resistance and color retention of coatings.

Technical Parameters

ItemDetails
Resin/Pigment TypePolyurethane / Selected weather-resistant pigments; available in white, black, light gray, or as per user requirements.
Surface FinishHigh gloss
Mixing RatioWeight ratio 6 (base material) : 1 (curing agent)
Curing AgentCPU1660
Specific GravityApproximately 1.2 kg/L
Volume Solids Content60% (theoretical)
Flash Point33°C (91.4°F)
Pot Life3 hours / 23°C
Theoretical Spread Rate12 m²/L (based on 50μm dry film thickness)
Single Coat ThicknessWet film: 100μm; Dry film: 60μm
Application MethodsBrush coating, airless spraying
Spray Nozzle (Airless)0.43-0.48mm
Outlet Pressure (Airless)15 MPa
ThinnerTH004
Tool Cleaning SolventTH004
VOC Content415 g/L
Drying TimeTouch dry: approx. 1 hour at 23°C, 50% relative humidity
Recoat TimeRefer to application guidelines
Recommended PrimersEpoxy primers or as specified
Ambient TemperatureMin: -10°C; Max: 50°C. Avoid application at relative humidity >85%.
Substrate TemperatureMin: 4°C above dew point
PackagingTwo-component, 21 kg combined packaging
Storage & Shelf LifeStore in compliance with national regulations. Keep in a cool, well-ventilated place away from excessive heat. Tightly seal containers. Shelf life: 1 year.

Application Guidelines

Surface Preparation
Before applying WH-PU166, the substrate must be free of grease, dust, moisture, and other contaminants and must have a suitable primer. To ensure film appearance, the primer should be smooth and free of surface defects such as dry spray and orange peel.
Mixing and Dilution
WH-PU166 is a two-component product requiring correct component ratio. Mix all material in each drum thoroughly before use. First, stir the base material until uniform and smooth (no more than 2 minutes), then slowly add the curing agent and stir for 3 minutes. A variable-speed power stirrer is recommended. Avoid over-stirring, as this may accelerate curing and shorten pot life. High temperatures shorten the mixture’s pot life, while low temperatures extend it. Dilution is generally not required; if necessary, add a small amount of thinner (5% or less) in compliance with local VOC and air quality regulations.
Application
WH-PU166 can be applied by airless spraying, roller coating, or conventional spraying.
Ventilation: Good ventilation in enclosed spaces is critical for applicator safety and product performance. Air must be dry, as application at humidity >85% is prohibited.
Recoat Time
Physical parameters at different ambient temperatures:

Ambient Temperature-10°C0°C10°C20°C30°C
Touch Dry2 days23h12h6h4h
Full Cure (RH 70%)2 months32 days14 days7 days5 days
Minimum Recoat Interval3 days1 day16h12h8h
Maximum Recoat IntervalUnlimitedUnlimitedUnlimitedUnlimitedUnlimited
Safety Measures
Warning: Irritating to eyes and skin. Vapors may cause respiratory allergies in sensitive individuals. May cause skin allergic reactions. Avoid inhaling vapors. Keep away from eyes and skin. Use protective equipment for eyes, ears, and skin. Use a suitable respirator to prevent potential respiratory irritation. Thoroughly wash skin after use. Wash contaminated clothing before reuse. In case of respiratory arrest, perform mouth-to-mouth resuscitation and seek medical attention immediately.
First Aid: In case of eye contact, flush with clean water for at least 15 minutes. Remove contaminated clothing and shoes, and wash affected skin with soap.
Declaration
The information herein is reliable. Each value is a theoretical data calculated from the product formula. Internal testing methods for the data can be provided upon request. Since usage conditions are beyond the manufacturer’s control, this information is not guaranteed. The product is for professional use only. For any questions, contact our company.
Our Technical Support and Customer Service Center is ready to provide product consultation and application technical services. Welcome to contact us by letter or phone.

Contact:

Wanhua Energysav Science & technology Group Co.,Ltd
Address: No. 56 Taiyuan Road, Yantai, Shandong, China
Fax: 400-059-1116 | Tel: +86-17761309662 | Postal Code: 264006
