PU165 Aliphatic Acrylic Polyurethane Topcoat

PU165 is an excellent two-component aliphatic acrylic polyurethane topcoat, semi-gloss, with high solid content and excellent gloss and color retention. When used with epoxy primer or polyurethane primer, a high-strength long-term anti-corrosion system can be obtained.

UNICHEM PU165 Aliphatic Acrylic Polyurethane Topcoat

Item	Description
General Overview	UM-PU165 is an excellent two-component aliphatic acrylic polyurethane topcoat with a semi-gloss finish. It features high solid content, exceptional light and color retention. When paired with epoxy or polyurethane primers, it forms a high-strength long-term anti-corrosion coating system.
Product Characteristics	– Excellent light and color retention – Good recoatability – Capable of low-temperature curing
Recommended Applications	Suitable as a protective topcoat for steel structures in moderate to highly corrosive atmospheric environments, where light and color fastness are required.
Technical Parameters
Resin/Pigment Type	Polyurethane / Selected weather-resistant pigments
Color	Customizable per client requirements
Sheen	Semi-gloss
Mixing Ratio	Weight ratio 13 (base material) : 1 (curing agent)
Curing Agent	CPU1650
Specific Gravity	Approximately 1.5 kg/L
Volume Solids	65 ± 2%
Flash Point	33°C (91.4°F)
Pot Life	2.5 hours at 20°C
Theoretical Coverage	13 m²/L (based on 50μm dry film thickness)
Single Coat Thickness	Wet film: 100μm; Dry film: 65μm
Application Method	Airless spraying
Nozzle Size (Airless Spraying)	0.43-0.48mm
Outlet Pressure (Airless Spraying)	15 MPa
Thinner	TH004
Tool Cleaning	TH004
Drying Time	Touch dry: approx. 2.5 hours at 20°C, 50% relative humidity
Recoat Time	Refer to application guidelines
Recommended Primers	Epoxy primer or as specified
Ambient Temperature	Min: -10°C; Max: 50°C. Avoid application at relative humidity >85%.
Substrate Temperature	Must be 3°C (5°F) above dew point to prevent condensation
Packaging	Two-component, 28kg combined packaging
Storage & Shelf Life	Store in accordance with national regulations. Keep in cool, well-ventilated areas away from excessive heat. Securely seal containers. Shelf life: 1 year.

Application Guidelines

| Surface Preparation | UM-PU165 requires the substrate to be free of grease, dust, moisture, and other contaminants, with a suitable primer applied. To ensure film appearance, the primer surface must be smooth, free of dry spray, orange peel, and other defects. |
| Mixing & Dilution | As a two-component product, UM-PU165 requires precise component ratio. Mix the entire contents of each paint pail before use. First, stir the base material until uniform and smooth (no more than 2 minutes), then slowly add the curing agent and stir for 3 minutes. A variable-speed power mixer is recommended. Avoid over-stirring, as this accelerates curing and shortens pot life. High temperatures reduce pot life; low temperatures extend it. Dilution is generally unnecessary. If required, add a small amount of thinner (5% or less) in compliance with local VOC and air quality regulations. |

Application
Tool	Dilution Max Volume	Application Parameters
Airless spraying	5%	Nozzle pressure: 14 MPa Nozzle size: 0.43-0.48mm
Air spraying	5%	Not applicable
Brush/roller	5%	Not applicable

Note: Brush or roller application may require multiple coats to achieve specified dry film thickness. Spraying parameters are indicative and can be adjusted on-site. Pressure values apply to materials at 20°C.

Ventilation: Maintain good ventilation in enclosed spaces to ensure worker safety and product performance. Air must be dry, as application at humidity >85% is prohibited.

Recoat Time (Atmospheric, Moderate Corrosion Environment)

Ambient Temperature	10°C	20°C	30°C	40°C
Recoat Interval	15 hours	10 hours	5 hours	2.5 hours

Safety Measures

Warning: Irritating to eyes and skin. Vapors may cause respiratory allergies in sensitive individuals. May induce skin allergic reactions. Avoid inhaling vapors. Keep away from eyes and skin. Use protective gear for eyes, ears, and skin. Use a suitable respirator to prevent potential respiratory irritation. Thoroughly wash skin after use. Launder contaminated clothing before reuse. In case of respiratory arrest, perform mouth-to-mouth resuscitation and seek immediate medical attention.
First Aid: In case of eye contact, flush with clean water for at least 15 minutes. Remove contaminated clothing and shoes, and wash affected skin with soap.

Notice

The information herein is reliable. Each value is theoretically calculated from the product formulation. UNICHEM can provide internal standard test methods for the data upon request. Since usage conditions are beyond the manufacturer’s control, this information does not constitute a warranty. The product is for professional use only. For inquiries, contact your local UNICHEM distributor.

Contact:

Wanhua Energysav Science & technology Group Co.,Ltd

Address: No. 56 Taiyuan Road, Yantai, Shandong, China

Fax: 400-059-1116 | Tel: +86-17761309662 | Postal Code: 264006
