EP152 Epoxy Mica Iron Oxide Intermediate Paint

EP152 is a two-component polyamide-cured epoxy mica iron oxide intermediate paint. The paint film exhibits excellent water resistance, abrasion resistance, and impermeability, along with outstanding corrosion resistance and superior low-temperature curing performance.

Inquiry Now
Name *
Email *
Enter enquiry subject *
Message *
WhatsApp
SKU: EP152 Epoxy Mica Iron Oxide Intermediate Paint Category: Tags: ,
Description

Overview

WH-EP152 is a two-component polyamide-cured epoxy mica iron oxide intermediate paint. The paint film exhibits excellent water resistance, abrasion resistance, and impermeability, along with outstanding corrosion resistance and superior low-temperature curing performance.

Recommended Applications

  • As an intermediate coat in epoxy paint systems for severe corrosion environments, or as a topcoat when decorative requirements are low.
  • As an intermediate coat or topcoat in low-temperature curing systems when decorative requirements are not strict.

Technical Parameters

ItemDetails
Binder/Pigment TypeEpoxy resin/mica iron oxide
ColorLight gray, red
Surface FinishFlat
Mixing Ratio9 (base material) : 1 (curing agent)
Curing AgentCEP1510
Specific GravityApprox. 1.5 kg/L
Volume Solids Content76% (theoretical)
Flash Point25°C
Pot Life2 hours at 23°C
Theoretical Coverage7.6 m²/L at 100μm dry film thickness
Single Coat Film ThicknessWet film: 132μm; Dry film: 100μm
Application MethodsBrush painting, airless spraying
Nozzle Size (Airless Spraying)0.48-0.53mm
Outlet Pressure (Airless Spraying)17.5 MPa
ThinnerTH003
VOC Content230 g/L
Drying TimeTouch dry: approx. 1 hour at 23°C
Recoating TimeRefer to application guidelines
Recommended PrimersSelf-priming or as specified
Ambient TemperatureMinimum: -10°C
PackagingTwo-component, 30kg combined packaging
Storage and Shelf LifeStore in compliance with national regulations, in a cool, well-ventilated place away from high temperatures. Containers must be tightly sealed. Shelf life: 1 year.

Application Guidelines

Surface Preparation
  • New Steel: Blast clean to Sa2.5 standard. When necessary, apply a suitable shop primer to protect the blasted surface. Before final application, thoroughly clean damaged shop primer and contaminated areas during storage and processing. Repair damaged areas with this product or other specified epoxy paints.
  • Maintenance: Remove grease with a suitable cleaner. Remove salts and other contaminants with high-pressure fresh water. Remove loose rust and other loose materials by blasting or power tools. Grind sharp edges, sweep away debris, and apply a complete paint film to achieve the original film thickness.
Mixing and Thinning
WH-EP152 is a two-component product with a precise component ratio. Use after fully mixing each barrel of paint. First, stir the base material until uniform and smooth, no more than 2 minutes, then slowly add the curing agent and stir for 3 minutes. A variable-speed power stirrer is recommended. Avoid over-stirring, as this will accelerate curing and shorten the product’s pot life. High temperatures will shorten the mixture’s pot life, while low temperatures will extend it. Generally, no thinning is required. If necessary, add a small amount of thinner (5% or less), subject to local VOC and air quality regulations.
Application
WH-EP152 can be applied by airless spraying, brush painting, and roller painting. Ensure good ventilation when applying in confined spaces. Avoid applying in the presence of standing water or rain. When using airless spraying, a pump with a ratio of 60:1 or higher is recommended. Use a 0.48-0.53mm nozzle and an output pressure of 175bar for good spraying results.
Recoating Time
Surface Temperature-10°C0°C10°C20°C30°C
Drying Time (hours)/Curing Time (days)36 hours/2 months16 hours/1 month8 hours/14 days4 hours/7 days3 hours/5 days
Minimum Recoating Interval (related to exposure environment):
Acrylic Paint
– Moderate atmospheric environment
– Severe atmospheric environment		18 hours
36 hours		9 hours
18 hours		4 hours
8 hours		2 hours
4 hours		1.5 hours
3 hours
Epoxy and Polyurethane Paint Series Recoating Interval
– Moderate atmospheric environment
– Severe atmospheric environment		36 hours
36 hours		18 hours
18 hours		8 hours
8 hours		4 hours
4 hours		3 hours
3 hours
Maximum Recoating Interval (related to exposure environment):
Acrylic Paint Recoating Interval
– Moderate atmospheric environment
– Severe atmospheric environment		3 days
2 days		36 hours
23 hours		16 hours
10 hours		8 hours
5 hours		6 hours
4 hours
Epoxy Paint Series Recoating Interval
– Moderate atmospheric environment
– Severe atmospheric environment		No limit
No limit		No limit
No limit		No limit
No limit		No limit
No limit		No limit
No limit
Polyurethane Paint Series Recoating Interval
– Moderate atmospheric environment
– Severe atmospheric environment		90 days
27 days		45 days
14 days		20 days
6 days		10 days
3 days		5 days
1.5 days

Safety Measures

  • Warning: Irritating to eyes and skin. Vapors may cause respiratory allergies in sensitive individuals. May cause skin allergic reactions. Avoid inhaling vapors. Do not contact eyes or skin. Wear protective equipment for ears, eyes, and skin. Use a suitable respirator to avoid potential respiratory irritation. Thoroughly wash skin after use. Wash clothes before reuse. If breathing stops, give mouth-to-mouth resuscitation and seek medical attention immediately.
  • First Aid: If accidentally in contact with eyes, rinse immediately with plenty of water for at least 15 minutes. Remove contaminated clothing and shoes, and wash the affected skin with soap.

Declaration

The information listed in this document is reliable. Each value provided is a theoretical data calculated from the product formula. If required, our company can inform the internal common measurement and determination methods for any of the above data. Since the use conditions are beyond the control of the manufacturer, the information here is not guaranteed. The product is for professional use only. If you have any questions, please contact our company.

Our Technical Support and Customer Service Center is willing to provide you with product consultation and application technical services. Welcome to contact us by letter or phone.

Contact:

Wanhua Energysav Science & technology Group Co.,Ltd
Address: No. 56 Taiyuan Road, Yantai, Shandong, China
Fax: 400-059-1116 | Tel: +86-17761309662 | Postal Code: 264006
