CR161 Chlorinated Rubber Topcoat
CR161 is a high-performance topcoat formulated with chlorinated rubber resin and corrosion-resistant pigments.
SKU:
CR161 Chlorinated Rubber Topcoat
Category: Corrosion Protection Coatings
Tags: Coating, Corrosion Protection Coatings
Description
General Description
WH-CR161 is a high-performance topcoat formulated with chlorinated rubber resin and corrosion-resistant pigments.
Product Features & Recommended Applications
- Features: Fast-drying, suitable for low-temperature painting; excellent corrosion resistance and seawater resistance.
- Applications:
- Can be used as an intermediate coat or topcoat for steel structures, including long-term immersion areas.
- Ideal for surface protection of marine engineering, ship steel structures above the waterline, electrochemical and chemical plants, as well as onshore steel surfaces (for protection and decoration).
Technical Parameters
Item | Details |
---|---|
Paint Type / Pigment Type | Chlorinated rubber / Corrosion-resistant pigments |
Color | Red, sea blue, or as per customer requirements |
Surface Finish | Flat |
Mixing Ratio | Single-component (no mixing required) |
Curing Agent | None |
Density | Approximately 1.5 kg/L |
Volume Solids Content | 45±1% (theoretical) |
Flash Point | 32℃ |
Pot Life | None |
Theoretical Spread Rate | 5.6 m²/L at 80μm dry film thickness |
Single Coat Thickness | Wet film: 175μm; Dry film: 80μm |
Application Methods | Brush painting, roller painting, airless spraying |
Nozzle Size (Airless) | 0.33-0.48 mm |
Outlet Pressure (Airless) | 18.6-24.1 MPa |
Thinner | TH016 |
Tool Cleaning Solvent | TH016 |
VOC Content | 475 g/L (theoretical) |
Drying Time | Touch-dry: 30 minutes (23℃) |
Environmental Temperature | Max: 40℃; avoid painting at relative humidity >85% (contact local agent for inquiries). |
Substrate Temperature | Min: 3℃ above dew point |
Packaging | Single-component, 20 kg/pail |
Storage & Shelf Life | Store in a cool, well-ventilated place away from high temperatures; keep containers tightly sealed. Shelf life: 1 year. |
Application Guidelines
Surface Preparation
WH-CR161 is designed for application on surfaces free of grease, dry soil, dust, moisture, and other contaminants. Ensure the surface is properly primed. For questions, contact your local representative.
Mixing & Dilution
- Mixing: As a single-component product, stir thoroughly for 2-3 minutes to achieve uniform consistency.
- Dilution: Dilution is generally unnecessary. If required (e.g., for application purposes), add a small amount of thinner (≤5%) in compliance with local VOC and air quality regulations.
Application
- Methods: Brush, roller, or airless spraying.
- Spraying Parameters: Nozzle size 0.33-0.48 mm; outlet pressure 18.6-24.1 MPa.
- Equipment Requirement: Ensure spraying equipment and fluid lines are clean, free of water and solvents, and operate carefully to achieve uniform film thickness.
- Ventilation: Good ventilation in enclosed areas is critical for worker safety and product performance. Avoid painting at humidity >85%.
Safety Precautions
- Hazards: May cause eye and skin irritation; vapor may irritate the respiratory tract of sensitive individuals; potential skin allergy risk.
- Protective Measures: Avoid inhaling vapor; keep away from eyes and skin. Use eye, ear, and skin protection; wear a suitable respirator to prevent respiratory irritation. Wash skin thoroughly after use.
- First Aid:
- If inhaled and breathing stops: Provide artificial respiration (preferably mouth-to-mouth) and seek medical help immediately.
- If in eyes: Flush with water for at least 15 minutes and consult a doctor.
- Wash contaminated clothing before reuse.
Disclaimer
The information herein is provided in good faith, with each value derived theoretically from the product formulation. Internal testing methods for the data can be disclosed upon request. Since usage conditions are beyond the manufacturer’s control, this information does not constitute a warranty. The product is for professional use only. For inquiries, contact our technical support and customer service center.
Contact:
Wanhua Energysav Science & technology Group Co.,Ltd
Address: No. 56 Taiyuan Road, Yantai, Shandong, China
Fax: 400-059-1116 | Tel: +86-17761309662 | Postal Code: 264006
