Fireproof Coating for Finishes SMT-S/WH01, 02

The SMT-S/WH 01, 02 comprises two water-based intumescent fireproof coatings designed for flammable substrates. While preserving the substrate’s appearance, they provide both fire protection and decorative finishes.

1. Product Overview

The SMT-S/WH series comprises two water-based intumescent fireproof coatings designed for flammable substrates. While preserving the substrate’s appearance, they provide both fire protection and decorative finishes.

Feature	SMT-S/WH01 (Opaque)	SMT-S/WH02 (Transparent)
Appearance	White, matte finish	Colorless transparent, semi-gloss finish
Composition	Single-component	Two-component (1.8:1 base-to-catalyst ratio)
Key Properties	High expansion ratio, eco-friendly, VOC-free	High clarity, retains substrate color, VOC-free
Primary Applications	Wood, fiberboard, plywood in buildings/hotels	Same as WH01, where transparency is required

2. Product Features

Feature	SMT-S/WH01	SMT-S/WH02
Appearance	White, matte finish	Colorless transparent, semi-gloss finish
Component Type	Single-component	Two-component (base material + curing agent)
VOC Emission	Zero	Zero
Key Decorative Feature	Smooth film, excellent decorative effect	High transparency, preserves substrate color
Mixing Ratio	N/A (ready-to-use)	1.8 (base material) : 1 (curing agent) (by weight)
Shelf Life	6 months	1 year

3.Technical Specifications

Item	SMT-S/WH01	SMT-S/WH02
Color	White	Colorless transparent
Surface Finish	Matte	Semi-gloss
Specific Gravity	~1.3 kg/L	~1.1 kg/L
Theoretical Coverage	500 g/m² (500μm dry film)	500 g/m² (500μm dry film)
Single-Coat Film Thickness	N/A	Wet: 350μm; Dry: 150μm
Application Methods	Brush, air spraying, airless spraying	Brush, air spraying (recommended for construction spray guns)
Diluent	Water (≤5% addition)	Water (≤5% addition)
Pot Life	N/A	2 hours @23℃
Drying Time (Surface Dry)	0.5 hours @23℃, 50% RH	4 hours @23℃, 50% RH
Packaging	Single-component, 25 kg	Two-component, 28 kg combo pack

4. Application Guidelines

Surface Preparation

Ensure the substrate is clean, dry, and free of oil, dust, and moisture.
For wood substrates: Plane and sand the surface, remove resin exudates with solvents (e.g., toluene), and apply a mildew-proofing agent if necessary.
Wood moisture content should be <10% for decorative surfaces and <12% for combustible substrates.

Mixing & Application

SMT-S/WH01: Stir thoroughly before use. Dilute with water (≤5%) if needed for viscosity adjustment.
SMT-S/WH02: Mix base material and curing agent at a 1.8:1 weight ratio. Stir slowly to avoid air bubbles; use a variable-speed mixer if available.
Application methods:
- SMT-S/WH01: Suitable for airless spraying, brush, or roller application. Cross-stripe coating (horizontal + vertical) is recommended for full coverage.
- SMT-S/WH02: Use construction spray guns (not ordinary air 喷枪) due to high viscosity. Apply 2–3 coats; allow natural drying between coats.

Recoating Interval

Environmental Temperature	SMT-S/WH01 (Matte White)	SMT-S/WH02 (Transparent Semi-Gloss)
5℃	16 hours (minimum)	16 hours (minimum)
15℃	8 hours (minimum)	8 hours (minimum)
25℃	4 hours (minimum)	4 hours (minimum)
35℃	1 hour (minimum)	1 hour (minimum)
45℃	10 minutes (minimum)	10 minutes (minimum)
Maximum Interval	7 days	7 days

Curing Conditions

Avoid rain within 24 hours after application.
For outdoor use, apply a topcoat to protect against UV aging (SMT-S/WH01) or water damage (SMT-S/WH02).

5. Safety Precautions

Wear protective gloves and goggles to avoid skin/eye contact and inhalation of paint mist.
Ensure good ventilation during application.

6. Storage & Shelf Life

Store in cool, dry, ventilated areas, away from high temperatures.
SMT-S/WH01: 6 months (sealed original packaging).
SMT-S/WH02: 1 year (sealed original packaging for each component).

Disclaimer

The information herein is based on reliable formulation data, but actual performance may vary due to uncontrollable application conditions. This product is intended for professional use only. For technical support or inquiries, please contact our Technical Support and Customer Service Center.

Contact:

Wanhua Energysav Science & technology Group Co.,Ltd

Address: No. 56 Taiyuan Road, Yantai, Shandong, China

Fax: 400-059-1116 | Tel: +86-17761309662 | Postal Code: 264006
