AC163 Acrylic Combined Primer and Topcoat Antirust Paint

WH-AC163 is a combined primer and topcoat antirust paint formulated with acrylic resin, non-chlorinated plasticizer, weather-resistant pigments, and antirust pigments (aluminum tripolyphosphate and zinc phosphate).

Name *
Email *
Enter enquiry subject *
Message *
SKU: AC163 Acrylic Combined Primer and Topcoat Antirust Paint Category: Tags: ,
Description

Overview

WH-AC163 is a combined primer and topcoat anti-rust paint formulated with acrylic resin, non-chlorinated plasticizer, weather-resistant pigments, and anti-rust pigments (aluminum tripolyphosphate and zinc phosphate).

Product Characteristics

  • Fast-drying
  • Anti-rust
  • Color-retentive

Recommended Applications

Suitable for use as a combined primer and topcoat anti-rust paint in light corrosion environments.

Technical Parameters

ItemDetails
Resin/Pigment TypeAcrylic resin / Weather-resistant pigments
ColorWhite, light gray, or customizable according to customer requirements
Surface FinishSemi-gloss
DensityApproximately 1.3 kg/L
Flash Point25°C (77°F)
Theoretical Spread Rate14.0 m²/L (based on 40μm dry film thickness)
Single Coat ThicknessWet film: 80μm; Dry film: 40μm
Application MethodsAirless spraying, brushing, rolling
Nozzle Size (Airless)0.33-0.48 mm
Outlet Pressure (Airless)15 MPa
ThinnerTH015
Tool Cleaning SolventTH015
VOC Content460 g/L
Drying TimeTouch-dry: 1 hour (23°C)
Recoating IntervalMinimum 4 hours, maximum unlimited at 23°C
Recommended PrimerAs specified
Environmental TemperatureMax. 40°C; avoid application at relative humidity >85%. Contact local agents for inquiries.
PackagingSingle-component, 20 kg container
Storage & Shelf LifeStore in compliance with national regulations. Keep in cool, well-ventilated areas away from excessive heat. Tightly seal containers. Shelf life: 1 year.

Application Guidelines

Surface Preparation
AC163 is designed for application on surfaces free of grease, dry soil, dust, moisture, and other contaminants. For inquiries, contact local offices.
Mixing and Dilution
  • AC163 is a single-pack product. Stir the paint for 2-3 minutes to achieve uniform consistency.
  • Dilution is generally unnecessary or undesirable. If required for application purposes, add a small amount of thinner (5% or less), subject to local VOC and air quality regulations.
Application
  • AC163 can be applied by traditional spraying, rolling, or airless spraying.
  • Nozzle size: 0.33-0.48 mm; Outlet pressure: 15 MPa.
  • Ensure equipment and fluid lines are clean, free of water and solvents, to achieve proper and uniform film thickness.
  • Ventilation: Good ventilation in enclosed areas is critical for applicator safety and optimal product performance.
  • Note: Avoid applying excessively thick coats.

Safety Measures

  • Warning: May cause eye and skin irritation. Vapors may cause respiratory irritation in sensitive individuals. May cause skin allergic reactions.
  • Avoid inhaling vapors. Keep away from eyes and skin. Use eye, ear, and skin protection equipment. Wear appropriate masks to prevent potential respiratory irritation.
  • Wash skin thoroughly with water after use. Consult a physician if discomfort occurs. Wash clothing before reuse.
  • In case of respiratory arrest, perform mouth-to-mouth resuscitation and seek medical attention immediately.
  • If contact with eyes occurs, flush with water for at least 15 minutes and seek immediate medical care.

Statement

The information listed in this document is reliable. Each value is a theoretical data calculated from the product formulation. Upon request, our company can provide internal standard measurement methods for the data provided above. Since the conditions of use are beyond the manufacturer’s control, this information does not constitute a guarantee. The product is for professional use only. For any questions, please contact our company.



Our Technical Support and Customer Service Center is ready to provide product consultation and application technical services. Welcome to contact us by letter or phone.


Contact:

Wanhua Energysav Science & technology Group Co.,Ltd
Address: No. 56 Taiyuan Road, Yantai, Shandong, China
Fax: 400-059-1116 | Tel: +86-17761309662 | Postal Code: 264006

Additional information
Weight 25 kg
