PU061 Polyurethane Varnish

PU061 is an excellent two-component polyurethane varnish, renowned for its exceptional weather resistance and color retention properties.

Overview

WH-PU061 is an excellent two-component polyurethane varnish, renowned for its exceptional weather resistance and color retention properties.

Recommended Applications	Features excellent chemical resistance, good recoatability, and low-temperature curability. Suitable for topcoating in anti-corrosion systems or protecting objects requiring color retention.
Technical Parameters
Resin/Pigment Type	Polyurethane
Color	Transparent
Surface Finish	Satin
Mixing Ratio	Weight ratio 6 (base material) : 1 (curing agent)
Curing Agent	CPU0610
Specific Gravity	Approximately 1.0 kg/L
Volume Solids	30% (theoretical)
Flash Point	33°C (91.4°F)
Pot Life	3 hours at 23°C
Theoretical Spread Rate	10.4 m²/L (based on 50μm dry film thickness)
Single Coat Thickness	Wet film: 100μm; Dry film: 30μm
Application Methods	Brush coating, airless spraying
Spray Nozzle (Airless)	0.43-0.48mm
Outlet Pressure (Airless)	15 MPa
Thinner	TH004
Tool Cleaning Agent	TH004
VOC Content	440 g/L
Drying Time	Touch dry: approx. 1 hour at 23°C, 50% relative humidity
Recoat Time	Refer to application guidelines
Recommended Primers	Suitable primers or topcoats, as specified
Storage & Shelf Life	Products must be stored in accordance with national regulations. Store in a cool, well-ventilated place away from excessive heat. Containers must be tightly sealed. Shelf life: 1 year.

Application Guidelines

Surface Preparation

Before applying WH-PU061, the substrate must be free of grease, dust, moisture, and other contaminants, and properly primed. To ensure film appearance, the primer should be smooth and free of surface defects such as dry spray or orange peel.

Mixing and Thinning

WH-PU061 is a two-component product requiring precise component ratio. Thoroughly mix the entire contents of each paint bucket before use. First, stir the base material until uniformly smooth (no more than 2 minutes), then slowly add the curing agent and stir for 3 minutes. A variable-speed power stirrer is recommended. Avoid over-stirring, as this may accelerate curing and shorten pot life. High temperatures reduce pot life, while low temperatures extend it. Thinning is generally unnecessary; if required, add a small amount of thinner (5% or less) in compliance with local VOC and air quality regulations.

Application

WH-PU061 can be applied by airless spraying, roller coating, or conventional spraying.
Ventilation: Maintaining good ventilation in enclosed spaces is critical for applicator safety and product performance. Air must be dry, as coating should not be performed at humidity exceeding 85%.

Recoat Time

Physical parameters at different ambient temperatures:

Ambient Temperature	-10°C	0°C	10°C	20°C	30°C
Touch Dry	3 days	36 hours	16 hours	8 hours	6 hours
Full Cure (RH 70%)	2 months	32 days	14 days	7 days	5 days
Recoat Interval	Minimum: 6 days	Minimum: 3 days	Minimum: 32 hours	Minimum: 16 hours	Minimum: 12 hours
(Between Recoats)	Maximum: Unlimited	Maximum: Unlimited	Maximum: Unlimited	Maximum: Unlimited	Maximum: Unlimited

Safety Measures

Warning: Causes eye and skin irritation. Vapors may trigger respiratory allergies in sensitive individuals. May cause skin allergic reactions. Avoid inhaling vapors. Keep away from eyes and skin. Use protective equipment for eyes, ears, and skin. Use a suitable respirator to prevent potential respiratory irritation. Thoroughly wash skin after use. Launder contaminated clothing before reuse. In case of respiratory arrest, perform mouth-to-mouth resuscitation and seek immediate medical attention.
First Aid: In case of eye contact, flush with water for at least 15 minutes. Remove contaminated clothing and shoes, and wash affected skin with soap.

Declaration

The information herein is provided in good faith. Each value is a theoretical data calculated from the product formula. Upon request, our company can disclose internal standard testing methods for the data provided. As usage conditions are beyond the manufacturer’s control, this information does not constitute a warranty. Products are for professional use only. For any questions, please contact our company.
Our Technical Support and Customer Service Center is ready to provide product consultations and application technical services. Welcome to contact us by letter or phone.

Contact:

Wanhua Energysav Science & technology Group Co.,Ltd

Address: No. 56 Taiyuan Road, Yantai, Shandong, China

Fax: 400-059-1116 | Tel: +86-17761309662 | Postal Code: 264006
