FC761 Fluorocarbon Metallic Paint

FC761 is an excellent two-component weather-resistant metallic effect topcoat. The extremely strong F-C bonds in its molecular structure endow the fluorocarbon paint with optimal UV aging resistance. The paint film exhibits superior weather resistance, color retention, and gloss retention properties. Additionally, the fluorocarbon paint features excellent self-cleaning properties, with a smooth surface that resists dirt adhesion.

Inquiry Now
Name *
Email *
Enter enquiry subject *
Message *
WhatsApp
SKU: FC761 Fluorocarbon Metallic Paint Category: Tags: ,
Description

Overview

WH-FC761 is an excellent two-component weather-resistant metallic effect topcoat. The extremely strong F-C bonds in its molecular structure endow the fluorocarbon paint with optimal UV aging resistance. The paint film exhibits superior weather resistance, color retention, and gloss retention properties. Additionally, the fluorocarbon paint features excellent self-cleaning properties, with a smooth surface that resists dirt adhesion.

Product Characteristics

  • Exceptional weather resistance
  • Outstanding color durability
  • Superior dirt resistance
  • Excellent abrasion resistance

Recommended Applications

Suitable as a topcoat for severely corrosive environments with extremely high requirements for paint weather resistance.

Technical Parameters

ItemDetails
Resin/Pigment TypeFluorocarbon resin / isocyanate / selected weather-resistant pigments
ColorSilver-white, or as per customer requirements
Surface SheenSatin
Mixing RatioWeight ratio 12 (base material) : 1 (curing agent)
Curing AgentCFC7610
Specific GravityApproximately 0.99 kg/L
Volume Solids Content45% (theoretical)
Flash Point33°C (91.4°F)
Pot Life3 hours / 23°C
Theoretical Spread Rate15 m²/L (based on 30μm dry film thickness)
Single Coat Film ThicknessWet film: 100μm, Dry film: 45μm
Application MethodsBrush coating, airless spraying
Spray Nozzle (Airless)0.43-0.48mm
Outlet Pressure (Airless)15 MPa
ThinnerTH005
VOC Content440 g/L
Drying TimeTouch dry: approx. 2 hours at 23°C, 50% relative humidity
Recoating IntervalRefer to application guidelines
Recommended PrimersPU111, EP111, EP141, or as specified
Ambient TemperatureMin: -10°C, Max: 50°C. Avoid application at relative humidity >85%.
Substrate TemperatureMin: 4°C above dew point
PackagingTwo-component, 20kg combined packaging
Storage & Shelf LifeMust be stored in accordance with national regulations. Store in a cool, well-ventilated place away from excessive heat. Keep containers tightly sealed. Shelf life: 1 year.

Application Guidelines

Surface Preparation
Before application, the substrate must be free of grease, dust, moisture, and other contaminants, and a suitable primer must be applied. To ensure the appearance of the paint film, the primer should be smooth and free of surface defects such as dry spray and orange peel.
Mixing and Dilution
FC761 is a two-component product requiring correct component ratio. Mix all materials in each drum thoroughly before use. First, stir the base material until uniform and smooth (no more than 2 minutes), then slowly add the curing agent and stir for 3 minutes. A variable-speed power stirrer is recommended. Avoid over-stirring, as this may accelerate curing and shorten the product’s pot life. High temperatures shorten the mixture’s working life, while low temperatures extend it. Dilution is generally not required; if necessary, add a small amount of thinner (5% or less) in compliance with local VOC and air quality regulations.
Application
FC761 can be applied by airless spraying, roller coating, or conventional spraying.
Ventilation: Maintaining good ventilation in enclosed spaces is critical for applicator safety and product performance. Air must be dry, as the product cannot be applied at humidity >85%.
Recoating Schedule
Ambient Temperature-10°C0°C10°C20°C30°C
Touch Dry3 days36h16h8h6h
Full Cure (RH: ≤85%)2 months32 days14 days7 days5 days
Minimum Recoat Interval6 days3 days32h16h12h
Maximum Recoat IntervalUnlimitedUnlimitedUnlimitedUnlimitedUnlimited

Safety Precautions

Warning: Irritating to eyes and skin. Vapors may cause respiratory allergies in sensitive individuals. May cause skin allergic reactions. Avoid inhaling vapors. Keep away from eyes and skin. Wear protective equipment for eyes, ears, and skin. Use a suitable respirator to avoid potential respiratory irritation. Thoroughly wash skin after use. Wash contaminated clothing before reuse. In case of respiratory arrest, perform mouth-to-mouth resuscitation and seek immediate medical attention.
First Aid: If contact with eyes occurs, rinse immediately with water for at least 15 minutes. Remove contaminated clothing and shoes, and wash affected skin with soap.

Disclaimer

The information provided herein is reliable. Each value is a theoretical data calculated from the product formulation. Upon request, our company can disclose the internal standard testing methods for the data above. Since the conditions of use are beyond the manufacturer’s control, this information does not constitute a guarantee. The product is for professional use only. For any questions, please contact our company.
Our Technical Support and Customer Service Center is ready to provide product consultation and application technical services. Welcome to contact us by letter or phone.

Contact:

Wanhua Energysav Science & technology Group Co.,Ltd
Address: No. 56 Taiyuan Road, Yantai, Shandong, China
Fax: 400-059-1116 | Tel: +86-17761309662 | Postal Code: 264006
