WH-AK161 is a premium topcoat formulated with carefully selected modified alkyd resins. It offers excellent gloss, weather resistance, flexible film properties, and saltwater resistance.
Product Characteristics
Exceptional decorative appeal with superior gloss and color retention
Excellent flexibility
Recommended Applications
Mechanical equipment with high aesthetic requirements and premium decorative projects
Available per our color chart; custom colors can be developed per client requirements
Surface Finish
Glossy
Mixing Ratio
Single-component (no mixing required)
Curing Agent
Not applicable
Specific Gravity
Approx. 1.1 kg/L
Volume Solids
42%
Flash Point
37°C
Pot Life
Not applicable
Theoretical Coverage
14 m²/L at 30 μm dry film thickness
Single Coat Film Thickness
Wet film: 70 μm; Dry film: 30 μm
Application Methods
Brush, roller, conventional spray, airless spray
Airless Spray Nozzle
0.33–0.48 mm
Airless Spray Pressure
12–18 MPa
Thinner
TH001
Tool Cleaning
TH001
VOC Content
Approx. 490 g/L
Drying Time
Touch-dry: approx. 5 hours at 23°C
Recoating Interval
Minimum: 16 hours (at 23°C)
Recommended Primers
Alkyd primers and suitable epoxy primers
Environmental Temperature
Max. 40°C (104°F); avoid application at relative humidity >85%
Substrate Temperature
Min. 3°C above dew point
Packaging
Single-component, 20 kg container
Storage & Shelf Life
Store in compliance with national regulations; keep in cool, well-ventilated areas away from excessive heat. Tightly seal containers. Shelf life: 1 year.
Certification
Certified by China Classification Society (CCS) for low flame spread
Smoke and toxicity performance complies with IMO FTPC Part 5 and IMO FTPC Part 2
Application Guidelines
Surface Preparation
WH-AK161 is designed for application on surfaces free of grease, dry soil, dust, moisture, and other contaminants, with a properly applied primer. For optimal appearance, the primer or intermediate coat should be smooth without surface defects (e.g., uneven spraying or severe orange peel).
Mixing and Thinning
As a single-component product, stir thoroughly for 2–3 minutes to achieve uniform consistency.
Thinning is generally unnecessary. If required (e.g., due to local VOC regulations or air quality standards), add no more than 5% TH001 thinner.
Application
Applicable by conventional spray, roller, or airless spray (nozzle: 0.33–0.48 mm; pressure: 12–18 MPa).
Ensure spraying equipment and pipelines are clean and free of water/solvents. Maintain careful control to achieve uniform film thickness.
Ventilation: Adequate ventilation in enclosed areas is critical for worker safety and proper product performance. Ensure dry air, as application at humidity >85% is prohibited.
Safety Precautions
Warning:
May cause eye and skin irritation. Vapors may trigger respiratory irritation in sensitive individuals and potential skin allergic reactions.
Avoid inhaling vapors. Keep away from eyes and skin. Use eye/ear/skin protection and appropriate respiratory masks to prevent irritation.
Wash skin thoroughly with water after use. Consult a physician if discomfort occurs. Launder clothing before reuse.
In case of respiratory arrest, perform mouth-to-mouth resuscitation and seek immediate medical attention. First Aid:
If contact with eyes occurs, flush with 清水 (clean water) for at least 15 minutes and consult a doctor immediately.
Disclaimer
The information herein is provided in good faith. All values are theoretical calculations based on product formulations. Internal testing methods can be disclosed upon request. Since application conditions are beyond the manufacturer’s control, this information does not constitute a warranty. For professional use only. Contact us for technical support or inquiries.
Technical Support & Customer Service
Our technical support and customer service center is available to provide product consultation and application technical services. Feel free to contact us via mail or phone.
Contact:
Wanhua Energysav Science & technology Group Co.,Ltd
Address: No. 56 Taiyuan Road, Yantai, Shandong, China
Fax: 400-059-1116 | Tel: +86-17761309662 | Postal Code: 264006
