FC161 Fluorocarbon Topcoat

WH-FC161 is an excellent two-component weather-resistant topcoat. The extremely strong F-C bonds in its molecular structure endow the fluorocarbon paint with optimal UV aging resistance. The paint film exhibits superior weather resistance, color retention, and gloss retention properties. Additionally, the fluorocarbon paint features excellent self-cleaning properties, with a smooth surface that resists contamination.

Inquiry Now
Name *
Email *
Enter enquiry subject *
Message *
WhatsApp
SKU: FC161 Fluorocarbon Topcoat Category: Tags: ,
Description

Overview

WH-FC161 is an excellent two-component weather-resistant topcoat. The extremely strong F-C bonds in its molecular structure endow the fluorocarbon paint with optimal UV aging resistance. The paint film exhibits superior weather resistance, color retention, and gloss retention properties. Additionally, the fluorocarbon paint features excellent self-cleaning properties, with a smooth surface that resists contamination.

Product Characteristics

  • Exceptional weather resistance
  • Outstanding color durability
  • Superior dirt resistance
  • Excellent abrasion resistance
  • Remarkable self-cleaning property with a smooth, contamination-resistant surface

Recommended Applications

Suitable as a topcoat for severely corrosive environments with extremely high requirements for paint weather resistance.

Technical Parameters

ItemDetails
Resin/Pigment TypeFluorocarbon resin / isocyanate / selected weather-resistant pigments
ColorWhite, black, or as per user requirements
Surface FinishSatin
Mixing RatioWeight ratio 12 (base material) : 1 (curing agent)
Curing AgentCFC1610
Specific GravityApproximately 1.2 kg/L
Volume Solids Content60% (theoretical)
Flash Point33°C (91.4°F)
Pot Life3 hours at 23°C
Theoretical Coverage10 m²/L (based on 60μm dry film thickness)
Single Coat ThicknessWet film: 100μm; Dry film: 60μm
Application MethodsBrush painting, airless spraying
Nozzle Size (Airless)0.43-0.48mm
Outlet Pressure (Airless)15 MPa
ThinnerTH005
VOC Content440 g/L
Drying TimeTouch dry: approx. 2 hours at 23°C, 50% relative humidity
Recoating IntervalRefer to application guidelines
Recommended PrimersPU111, EP111, EP141, or as specified
Ambient TemperatureMin: -10°C; Max: 50°C. Avoid application at relative humidity >85%.
Substrate TemperatureMin: 4°C above dew point
PackagingTwo-component, 20 kg combined packaging
Storage & Shelf LifeMust be stored in accordance with national regulations. Keep in a cool, well-ventilated place away from excessive heat. Tightly seal containers. Shelf life: 1 year.

Application Guidelines

Surface Preparation
Before application, ensure the substrate is free of grease, dust, moisture, and other contaminants, and has appropriate primer coating. To ensure film appearance, the primer should be smooth and free of surface defects such as dry spray and orange peel.
Mixing and Dilution
FC161 is a two-component product requiring correct component ratio. Mix all contents of each paint bucket thoroughly before use. First, stir the base material until uniform and smooth (no more than 2 minutes), then slowly add the curing agent and stir for 3 minutes. A variable-speed power stirrer is recommended. Avoid over-stirring, as this may accelerate curing and shorten the product’s pot life. High temperatures shorten the mixture’s working life, while low temperatures extend it. Dilution is generally not required; if necessary, add a small amount of thinner (5% or less) in compliance with local VOC and air quality regulations.
Application
FC161 can be applied by airless spraying, roller coating, or conventional spraying.
Ventilation
Maintaining good ventilation in enclosed spaces is critical for applicators’ safety and the product’s proper performance. Air must be dry, as application is not permitted at humidity >85%.
Physical Parameters at Different Ambient Temperatures
Ambient Temperature-10°C0°C10°C20°C30°C
Touch Dry3 days36h16h8h6h
Full Cure (RH 70%)2 months32 days14 days7 days5 days
Minimum Recoating Interval (from previous coat)6 days3 days32h16h12h
Maximum Recoating IntervalUnlimitedUnlimitedUnlimitedUnlimitedUnlimited
Safety Precautions
  • Warning: Irritating to eyes and skin. Vapors may cause respiratory allergies in sensitive individuals. May cause skin allergic reactions. Avoid inhaling vapors. Keep away from eyes and skin. Use protective equipment for eyes, ears, and skin. Use a suitable respirator to avoid potential respiratory irritation. Thoroughly wash skin after use. Wash contaminated clothing before reuse. In case of respiratory arrest, provide mouth-to-mouth resuscitation and seek immediate medical attention.
  • First Aid: If contact with eyes occurs, immediately flush with clean water for at least 15 minutes. Remove contaminated clothing and shoes, and wash affected skin with soap.
Declaration
The information herein is reliable, and each value is theoretically calculated from the product formulation. Upon request, our company can provide internal standard test methods for the data listed above. Since the conditions of use are beyond the manufacturer’s control, this information is not provided as a guarantee. The product is for professional use only. For any questions, please contact our company.

Our Technical Support and Customer Service Center is ready to provide product consulting and application technical services. Welcome to contact us by letter or phone.

Contact:

Wanhua Energysav Science & technology Group Co.,Ltd
Address: No. 56 Taiyuan Road, Yantai, Shandong, China
Fax: 400-059-1116 | Tel: +86-17761309662 | Postal Code: 264006
