EZ072 Epoxy Zinc Rich Primer

EZ072 is a two-component epoxy zinc-rich primer that provides cathodic protection for steel substrates.

Inquiry Now
Name *
Email *
Enter enquiry subject *
Message *
WhatsApp
SKU: EZ072 Epoxy Zinc Rich Primer Category: Tags: ,
Description

Overview

WH-EZ072 is a two-component epoxy zinc-rich primer that provides cathodic protection for steel substrates.

Product Characteristics

  • Hard and wear-resistant film
  • Excellent corrosion protection performance
  • Superior coating application properties

Recommended Applications

  • Anticorrosion of steel structures
  • Coating on container production lines

Technical Parameters

ItemDetails
Paint Type/Pigment TypeEpoxy resin, polyamide/metallic zinc pigment, anti-rust pigment
ColorZinc gray, grayish red
Surface FinishMatte
Mixing RatioWeight ratio 9 (base material) : 1 (curing agent)
Curing AgentCEZ0700
DensityApproximately 2.2 kg/L
Volume Solids Content50% (theoretical value)
Flash Point>30℃
Pot Life8 hours (23℃)
Theoretical Coverage12.5 m²/L (calculated at 40μm dry film thickness)
Single Film ThicknessWet film: 80μm; Dry film: 40μm
Application MethodAirless spraying, air spraying
Nozzle Size (Airless)0.43-0.58 mm
Outlet Pressure (Airless)15 MPa
Thinner/CleanerTH003
VOC Content450 g/L
Drying TimeTouch dry: 30 minutes (23℃; 50% RH); Full cure: 7 days (23℃)
Recoat IntervalMinimum: 4 hours (23℃)
Recommended PrimerNone
Environmental TemperatureMin: 5℃; Max: 40℃. Avoid application under relative humidity >85%.
Substrate TemperatureMinimum: 3℃ above dew point temperature
PackagingTwo-component, 30 kg combined packaging
Storage & Shelf LifeStore in accordance with national regulations. Keep in cool, well-ventilated places, away from excessive heat. Tightly seal containers. Shelf life: 1 year.

Application Guidelines

Surface Preparation
WH-EZ072 is designed for direct application on steel surfaces pre-treated by sandblasting to Sa2.5 grade in accordance with Swedish standard SIS055900. All surfaces must be free of grease, moisture, or other contaminants before sandblasting. For any questions, contact…
Mixing and Dilution
As a two-component product, WH-EZ072 requires strict proportional mixing. First, stir the base material until smooth and uniform (no more than 2 minutes). After the base material is uniform, slowly and continuously add the curing agent and stir for 3 minutes. Allow a 1-2 minute induction time before application. Dilution is generally not required or recommended, as excessive dilution may negatively affect coating application and appearance. A variable-speed electric stirrer is recommended. Avoid over-stirring, as this may accelerate curing and reduce pot life. Higher temperatures shorten pot life, while lower temperatures extend it.
Application
WH-EZ072 can be applied by conventional spraying or airless spraying. When using airless equipment, a Graco 30:1 pump with a nozzle size of 0.43-0.58 mm is recommended to ensure smooth material flow. To achieve optimal coating results, ensure equipment and fluid lines are clean and free of water and solvents. Maintain a recommended spray angle of 40°-70° for uniform film thickness. For roller application, use new short-fine nap rollers.

Safety Precautions

  • Warning: May cause eye and skin irritation. Vapors may cause respiratory irritation in sensitive individuals. May cause skin allergic reactions.
  • Avoid inhaling vapors. Do not contact eyes or skin. Use appropriate eye, ear, and skin protection, as well as a suitable respirator to prevent potential respiratory irritation.
  • Thoroughly wash skin with water after use. Consult a physician if discomfort occurs. Wash clothing before reuse.
  • In case of respiratory arrest, perform mouth-to-mouth resuscitation and seek medical attention immediately.
  • If contact with eyes occurs, rinse immediately with water for at least 15 minutes and seek medical help promptly.

Declaration

The information listed in this document is reliable. Each provided value is a theoretical data calculated from the product formula. If needed, our company can disclose the internal common measurement methods for the above data. Since the usage conditions are beyond the manufacturer’s control, this information does not constitute a guarantee. The product is for professional use only. For any questions, please contact our company.

Our Technical Support and Customer Service Center is ready to provide product consultation and application technical services. Welcome to contact us by letter or phone.

Contact:

Wanhua Energysav Science & technology Group Co.,Ltd
Address: No. 56 Taiyuan Road, Yantai, Shandong, China
Fax: 400-059-1116 | Tel: +86-17761309662 | Postal Code: 264006
