WD161 Waterborne Amino Baking Paint

WD161 is an environmentally friendly baking paint using water as the dispersion medium, offering advantages such as low production cost, non-flammability, non-toxicity, environmental friendliness, and organic solvent savings

Inquiry Now
Name *
Email *
Enter enquiry subject *
Message *
WhatsApp
SKU: WD161 Waterborne Amino Baking Paint Category: Tags: ,
Description
Product Features
WD161 is an environmentally friendly baking paint using water as the dispersion medium, offering advantages such as low production cost, non-flammability, non-toxicity, environmental friendliness, and organic solvent savings. It is non-flammable and non-explosive, facilitating safe transportation. Diluted with deionized water and cleaned with deionized water for tools, equipment, and containers, it significantly reduces coating costs. It also features excellent light and color retention, durability, high hardness, strong adhesion, and superior chemical resistance.

Recommended Applications
Suitable for baking line coating of automotive hubs, rims, brake discs, packaging steel drums, chemical iron drums, and other metal components.

Technical Parameters

ItemSpecification
ColorCustomized as per customer requirements
Specific Gravity (kg/L)1.20±0.05
Volume Solids Content35%
Coating Film Thickness (μm)30-50
Coverage (㎡/L)Theoretical: 8-9 ㎡/L/40μm
Practical: Varies with surface treatment, spraying environment, construction method, and structure of coated objects
Flash PointNot applicable
Drying Conditions120-160℃ for 20-30 minutes
GlossinessAs agreed
Fineness (μm)≤30
Flexibility (mm)≤2
Impact Resistance≥50
Film Hardness≥H
Adhesion (Circle Scoring Method)Grade 0
Artificial Accelerated Aging≥600h

Construction Guidelines

  • Pre-coating Compatibility: Directly apply over electrophoretic primer surfaces or acid-pickled and phosphated steel surfaces.
  • Application Instructions: Strictly avoid contact with oily substances. Stir thoroughly before use. 适当加水稀释 (appropriately dilute with water), with a recommended water addition of 5-30%.

Storage and Transportation

  • Store at ≥0℃ in a cool, dry place, protected from freezing and direct sunlight. Shelf life: 12 months.
  • During transportation, protect from rain and sunlight. Store in a cool, ventilated area away from direct sunlight.

Safety Measures

  • Warning: May cause eye and skin irritation. Vapors may trigger respiratory allergies in sensitive individuals and potential skin allergic reactions. Avoid inhaling vapors. Prevent contact with eyes and skin. Use protective gear for eyes, ears, and skin. Use a suitable respirator to avoid potential respiratory irritation. Thoroughly wash skin after use. Wash contaminated clothing before reuse. In case of respiratory arrest, perform mouth-to-mouth resuscitation and seek immediate medical attention.
  • First Aid: In case of eye contact, flush with clean water for at least 15 minutes. Remove contaminated clothing and shoes, and wash affected skin with soap.

Declaration
The information in this document is reliable. Each listed value is a theoretical data calculated from the product formula. Upon request, our company can disclose the internal common measurement methods for the provided data. Since the use conditions are beyond the manufacturer’s control, this information does not constitute a guarantee. The product is for professional use only. For any questions, please contact our company. Our Technical Support and Customer Service Center are ready to provide product consultation and application technical services. Welcome to contact us by letter or phone.
