EP153 Epoxy Glass Flake Coating

EP153 is a two-component polyamide-cured epoxy glass flake coating. The paint film exhibits excellent water resistance, abrasion resistance, and impermeability.

Inquiry Now
Name *
Email *
Enter enquiry subject *
Message *
WhatsApp
SKU: EP153 Epoxy Glass Flake Coating Category: Tags: ,
Description

General Description

WH-EP153 is a two-component polyamide-cured epoxy glass flake coating. The paint film exhibits excellent water resistance, abrasion resistance, and impermeability.

Product Features

  • Exceptional corrosion resistance
  • Superior low-temperature curing performance

Recommended Applications

  • Can be used as an intermediate coat or topcoat (for non-high decorative requirements) in epoxy paint systems under severe corrosion environments.
  • Suitable for intermediate coats or topcoats (for non-high decorative requirements) in low-temperature curing systems.

Technical Parameters

ItemDetails
Base/Pigment TypeEpoxy resin/glass flakes
ColorLight gray, red, etc.
Surface FinishFlat
Mixing RatioWeight ratio 9 (base material) : 1 (curing agent)
Curing AgentCEP1510
Specific GravityApproximately 1.45 kg/L
Volume Solids65% (theoretical)
Flash Point25°C
Pot Life2 hours/23°C
Theoretical Spread Rate6.5 m²/L at 100μm (4 mils) dry film thickness
Single Coat ThicknessWet film: 155μm; Dry film: 100μm
Application MethodsBrush coating, airless spraying
Nozzle Size (Airless Spraying)0.48-0.53mm
Outlet Pressure (Airless Spraying)17.5 MPa
ThinnerTH003
VOC Content430 g/L
Drying TimeTouch dry: approx. 1 hour/23°C
Recoating TimeRefer to application guidelines
Recommended PrimersSelf-priming or as specified
Ambient TemperatureMinimum: -10°C
PackagingTwo-component, 25 kg combined packaging
Storage & Shelf LifeStore in compliance with national regulations; keep in cool, well-ventilated places away from high temperatures. Tightly seal containers. Shelf life: 1 year.

Application Guidelines

Surface Preparation
  • New Steel: Blast to Sa2.5 standard. If necessary, apply a suitable shop primer to protect the blasted surface. Before final application, thoroughly clean damaged shop primer and contaminated areas during storage and processing. Repair damaged parts with this product or other specified epoxy paints.
  • Maintenance: Remove grease with appropriate cleaners. Eliminate salts and other contaminants with high-pressure fresh water. Remove loose rust and other loose materials by blasting or power tools. Grind sharp edges, sweep away debris, and apply a complete paint film to achieve the original film thickness.
Mixing and Dilution
WH-EP153 is a two-component product requiring correct component ratio. Use the entire contents of each drum after thorough mixing. First, stir the base material until uniform and smooth (no more than 2 minutes), then slowly add the curing agent and stir for 3 minutes. A variable-speed power stirrer is recommended. Avoid over-stirring to prevent accelerated curing and shortened pot life. High temperatures shorten the mixture’s pot life, while low temperatures extend it. Dilution is generally not required; if necessary, add a small amount of thinner (5% or less) in compliance with local VOC and air quality regulations.
Application
WH-EP153 can be applied by airless spraying, brush, or roller. Ensure good ventilation in confined spaces. Avoid application in the presence of standing water or rain. For airless spraying, a pump with a 60:1 (or higher) ratio is recommended. Use a 0.48-0.53mm nozzle with an output pressure of 175 bar for optimal spraying results.
Recoating Time Table
Surface Temperature-10°C0°C10°C20°C30°C
Drying Time (hours)/Curing Time (days)36/6016/308/144/73/5
Minimum Recoating Interval (Environment-dependent):
– Acrylic Paints
– Moderate Atmosphere
– Severe Atmosphere		18h
36h		9h
18h		4h
8h		2h
4h		1.5h
3h
– Epoxy & Polyurethane Paints
– Moderate/Severe Atmosphere		36h
36h		18h
18h		8h
8h		4h
4h		3h
3h
Maximum Recoating Interval (Environment-dependent):
– Acrylic Paints
– Moderate Atmosphere
– Severe Atmosphere		72h
48h		36h
23h		16h
10h		8h
5h		6h
4h
– Epoxy Paints
– Moderate/Severe Atmosphere		No limitNo limitNo limitNo limitNo limit
– Polyurethane Paints
– Moderate Atmosphere
– Severe Atmosphere		90d
27d		45d
14d		20d
6d		10d
3d		5d
1.5d

Safety Measures

  • Warning: Irritating to eyes and skin. Vapors may cause respiratory allergies in sensitive individuals. May cause skin allergic reactions. Avoid inhaling vapors. Keep away from eyes and skin. Wear protective gear for ears, eyes, and skin. Use a suitable respirator to prevent potential respiratory irritation. Thoroughly wash skin after use. Wash contaminated clothing before reuse. In case of respiratory arrest, perform mouth-to-mouth resuscitation and seek immediate medical attention.
  • First Aid: If contact with eyes occurs, flush with clean water for at least 15 minutes. Remove contaminated clothing and shoes, and wash affected skin with soap.

Declaration

The information listed in this document is reliable. Each value is a theoretical data calculated from the product formula. If required, our company can provide internal standard test methods for the above data. Since the usage conditions are beyond the manufacturer’s control, this information is not provided as a guarantee. The product is for professional use only. For any questions, please contact our company.

Contact:

Wanhua Energysav Science & technology Group Co.,Ltd
Address: No. 56 Taiyuan Road, Yantai, Shandong, China
Fax: 400-059-1116 | Tel: +86-17761309662 | Postal Code: 264006
