CLARNATE A1285
Description
CLARNATE® A1285 Polycarbonate Resin
Basic Information
Features | • Low melt viscosity • Excellent mold release property |
|---|---|
| Application | • General purpose |
| Appearance | • Transparent pellets |
| Processing Method | • Injection molding |
Product Properties
| Property | Test Standard | Test Condition | Unit | Typical Value |
|---|---|---|---|---|
| Physical Properties | ||||
| Melt Flow Index | ASTM D1238 | 300℃/1.2kg | g/10min | 27 |
| Mold Shrinkage | ASTM D955 | - | % | 0.5-0.7 |
| Water Absorption | ASTM D570 | 23℃, 24h | % | 0.2 |
| Density | ASTM D792 | - | g/cm³ | 1.2 |
| Mechanical Properties | ||||
| Tensile Strength | ASTM D638 | 50mm/min | MPa | 62 |
| Tensile Modulus | ASTM D638 | 1mm/min | MPa | 2300 |
| Yield Stress | ASTM D638 | 50mm/min | MPa | 62 |
| Yield Strain | ASTM D638 | 50mm/min | % | 6 |
| Elongation at Break | ASTM D638 | 50mm/min | % | 115 |
| Flexural Strength | ASTM D790 | 2mm/min | MPa | 90 |
| Flexural Modulus | ASTM D790 | 2mm/min | MPa | 2300 |
| Izod Notch Impact Strength | ASTM D256 | 23℃ | J/m | 700 |
| Thermal Properties | ||||
| HDT (Unannealed) | ASTM D648 | 1.82MPa;3.2mm | ℃ | 125 |
| Vicat Softening Point (Unannealed) | ASTM D1525 | 120℃/h;50N | ℃ | 148 |
| Optical Properties | ||||
| Haze | ASTM D1003 | 3mm | % | <0.8 |
| Light Transmittance | ASTM D1003 | 3mm | % | 90 |
| Refractive Index | ASTM D542 | - | - | 1.586 |
| Flammability | ||||
| Flammability Rating | UL 94 | 3mm | - | HB |
| UL 94 | 1.5mm | - | V2 | |
| Electrical Properties | ||||
| Relative Permittivity | IEC 60250 | 100Hz | - | 3.1 |
| IEC 60250 | 1MHz | - | 3.0 | |
| Dissipation Factor | IEC 60250 | 100Hz | 10⁻⁴ | 5 |
| IEC 60250 | 1MHz | 10⁻⁴ | 90 | |
| Volume Resistivity | IEC 60093 | - | Ω·m | 10¹⁴ |
| Surface Resistivity | IEC 60093 | - | Ω | 10¹⁶ |
| Dielectric Strength | IEC 60243-1 | 1mm | kV/mm | 34 |
| Comparative Tracking Index (CTI) | IEC 60112 | Solution A | V | 250 |
| Processing Parameters | ||||
| Pre-drying Temperature | ℃ | 120 | ||
| Pre-drying Time | h | 5 | ||
| Injection Melt Temperature | ℃ | 270-290 | ||
| Mold Temperature | ℃ | 80 | ||
| Injection Speed | mm/s | 50 |
Version Information
Initial Release Date: Jan 25, 2021 Version: V1.0
All specifications and data stated herein are compiled based on our existing technical knowledge and practical experience for reference only. Binding specifications shall be subject to the quality certificate or supply contract. Purchasers shall conduct independent testing to verify product suitability for designated processes and end applications prior to use. As downstream processing and application of our products are beyond our control, our liability shall be limited only to the supplied goods and we shall not be liable for any consequential losses arising from subsequent production using our materials. Wanhua’s Technical Support & Customer Service Center provides professional technical consultation and application support upon request.
